New Type Negative Pressure Cement Fineness Sieve Analyzer

New Type Negative Pressure Cement Fineness Sieve Analyzer

1、Uses

FYS-150 environment-friendly intelligent digital display negative pressure screen analyzer is widely used in cement fineness test and cement production control, and can be used for powder fineness test in other industries at the same time.

3、Technical data

1、Voltage ： 220V±10%

2、test fineness 80μm ，45μm

3、Screen analysis control time 2min（Factory set）

4、Adjustable range of working negative pressure ： 0 – 10000pa

5、Accuracy of measurement： ±100pa

6、resolution： 10pa

7、Work environment： Temperature 0~50°C ,humidity＜85%RH

8、Nozzle rotate speed ： 30 ±2r /min

9、Distance between nozzle and screen ： 2—8mm

10、Cement sample： 25g

11、Power： 600W

12、Noise： ≤75dB

13、Net weight ： 40kg

---
